Description
DS-2CE16H0T-ITPFS (5 MP OUTDOOR HIKVISION CAMERA)
5 MP Audio Fixed Mini Bullet Camera
- 5 MP coaxial audio camera
- Enhanced safety with discreet and economical built-in microphone
- Transmit audio over coaxial cable
- EXIR 2.0: advanced infrared technology with 25 m IR distance
- Water and dust resistant (IP67)
- 4 in 1 (4 signals switchable TVI/AHD/CVI/CVBS)
Available models:
DS-2CE16H0T-ITPFS(2.8mm)
- Camera
- Image Sensor5 MP CMOS
- Max. Resolution2560 (H) Ć 1944 (V)
- Min. Illumination0.01 Lux@(F1.2, AGC ON), 0 Lux with IR
- Shutter Time
PAL: 1/25 s to 1/50, 000 s
NTSC: 1/30 s to 1/50, 000 s
- Day & NightICR
- Angle AdjustmentPan: 0 to 355Ā°, Tilt: 0 to 75Ā°, Rotation 0 to 355Ā°
- Signal SystemPAL/NTSC
- Lens
- Lens Type2.8 mm, 3.6 mm, 6 mm fixed lens
- Focal Length & FOV
2.8 mm, horizontal FOV: 85.5Ā°,vertical FOV: 63.7Ā°, diagonal FOV: 110.7Ā°
3.6 mm, horizontal FOV: 80.1Ā°, vertical FOV: 63.7Ā°, diagonal FOV: 105.9Ā°
6 mm, horizontal FOV: 57.1Ā°, vertical FOV: 43.1Ā°, diagonal FOV: 72.5Ā°
- Lens MountM12
- Image
- Image SettingsBrightness, Sharpness, Mirror, Smart IR
- Frame Rate
TVI: 5MP@20fps, 4MP@30fps, 4MP@25fps, 1080P@30fps, 1080P@25fps
CVI: 4MP@30fps, 4MP@25fps
AHD: 5MP@20fps, 4MP@30fps, 4MP@25fps
CVBS: PAL/NTSC
- Day/Night ModeAuto/Color/BW (Black and White)
- Image EnhancementBLC
- White BalanceATW/MANUAL
- AGCSupport
- Interface
- Video OutputSwitchable TVI/AHD/CVI/CVBS
- General
- MaterialPlastic
- Dimension58 mm Ć 61 mm Ć 158.6 mm (2.28″ Ć 2.40″ Ć 6.42″)
- Approx. 160 g (0.35 lb.)
- Operating Condition-40Ā° C to 60Ā° C (-40Ā° F to 140Ā° F), Humidity 90% or less (no condensation)
- CommunicationHIKVISION-C
- LanguageEnglish
- Power Supply
12 VDC Ā± 25%
*You are recommended to use one power adapter to supply the power for one camera.
- Consumption
Max. 3.7 W
- IR RangeUp to 25 m
- Approval
- ProtectionIP67
