DS-2CE16H0T-ITPFS (5 MP OUTDOOR HIKVISION CAMERA)

SKU: N/A
Compare

KWD 9.250

Compare

Description

DS-2CE16H0T-ITPFS (5 MP OUTDOOR HIKVISION CAMERA)

5 MP Audio Fixed Mini Bullet Camera

  • 5 MP coaxial audio camera
  • Enhanced safety with discreet and economical built-in microphone
  • Transmit audio over coaxial cable
  • EXIR 2.0: advanced infrared technology with 25 m IR distance
  • Water and dust resistant (IP67)
  • 4 in 1 (4 signals switchable TVI/AHD/CVI/CVBS)

Available models:

DS-2CE16H0T-ITPFS(2.8mm)
  • Camera
  • Image Sensor5 MP CMOS
  • Max. Resolution2560 (H) Ɨ 1944 (V)
  • Min. Illumination0.01 Lux@(F1.2, AGC ON), 0 Lux with IR
  • Shutter Time

    PAL: 1/25 s to 1/50, 000 s

    NTSC: 1/30 s to 1/50, 000 s

  • Day & NightICR
  • Angle AdjustmentPan: 0 to 355Ā°, Tilt: 0 to 75Ā°, Rotation 0 to 355Ā°
  • Signal SystemPAL/NTSC
  • Lens
  • Lens Type2.8 mm, 3.6 mm, 6 mm fixed lens
  • Focal Length & FOV

    2.8 mm, horizontal FOV: 85.5Ā°,vertical FOV: 63.7Ā°, diagonal FOV: 110.7Ā°

    3.6 mm, horizontal FOV: 80.1Ā°, vertical FOV: 63.7Ā°, diagonal FOV: 105.9Ā°

    6 mm, horizontal FOV: 57.1Ā°, vertical FOV: 43.1Ā°, diagonal FOV: 72.5Ā°

  • Lens MountM12
  • Image
  • Image SettingsBrightness, Sharpness, Mirror, Smart IR
  • Frame Rate

    TVI: 5MP@20fps, 4MP@30fps, 4MP@25fps, 1080P@30fps, 1080P@25fps

    CVI: 4MP@30fps, 4MP@25fps

    AHD: 5MP@20fps, 4MP@30fps, 4MP@25fps

    CVBS: PAL/NTSC

  • Day/Night ModeAuto/Color/BW (Black and White)
  • Image EnhancementBLC
  • White BalanceATW/MANUAL
  • AGCSupport
  • Interface
  • Video OutputSwitchable TVI/AHD/CVI/CVBS
  • General
  • MaterialPlastic
  • Dimension58 mm Ɨ 61 mm Ɨ 158.6 mm (2.28″ Ɨ 2.40″ Ɨ 6.42″)
  • Approx. 160 g (0.35 lb.)
  • Operating Condition-40Ā° C to 60Ā° C (-40Ā° F to 140Ā° F), Humidity 90% or less (no condensation)
  • CommunicationHIKVISION-C
  • LanguageEnglish
  • Power Supply

    12 VDC Ā± 25%

    *You are recommended to use one power adapter to supply the power for one camera.

  • Consumption

    Max. 3.7 W

  • IR RangeUp to 25 m
  • Approval
  • ProtectionIP67
